Our chart (click on Related Content tab to download) shows aftermarket comparisons for most popular transponder key blanks. With few exceptions, the blanks are designed for duplication and key origination. A list of keys designed especially for cloning will be listed in a subsequent issue. This listing was compiled from information currently available and may not contain additional key blanks added since this list was compiled.
For further information contact your local locksmith distributor or the following transponder key blank manufacturers.:
Bianchi USA: Phone: 800-891-2118. Web: www.bianchi1770usa.com
Kaba-IlcoCorp.: Phone: 800-334-1381. Web: www.kaba-ilco.com
Hata Inc.: Phone: 866-888-4282. Web: www.hatainc.com
Jet Hardware: Phone: 718-257-9600. Web: www.jetkeys.com
STRATTEC: Phone: 414-247-3361. Web: aftermarket.strattec.com
JMA USA: Phone: 817-385-4850. Web: www.jmausa.com
To read additional Locksmith Ledger articles about transponder programming, visit http://tinyurl.com/trans313.
Transponder Comparisons
BIANCHI ILCO HATA JET STRATTEC JMA
CHRYSLER
BY165-PT Y164-PT HAT-1718 Y165-PHT 692352 -
BY170-PT Y170-PT HAT-3740 Y166-PHT 5909874 -
BY160-PT Y160-PT Y160-HPT Y160-PHT 692325 TP21VCHR-15.P
- Y165-PT HAT-0654 - 692353 TP12CHR-15.P
DAEWOO
BDW05T5 DW05T5 - DW47R-N-PHT - -
BDW05RT5 DW05RT5 - DW47-N-PHT - -
BDW04RT5 DW04RT5 - DW48R-N-PHT - -
FIAT
FT22UTK100 SIP22EHP-SI - FT70-ETK-C3 - -
FORD
BH73-PT H73-PT - H73-PHT 692055 TP02FO-16.P
BH72-PT H72-PT H72-HPT H72-PHT 598333 TP02FO-15D.P
BJ92-PT - - - - TP33FO-30D.P
BH86-PT H86-PT H86-HPT H86-PHT 691643 -
BH84-PT H84-PT HAT-9114 H84-PHT 599114 TP20FO-30D.P
BFD40TK14 HU101T17 - - - -
BFD3TK14 FO21T17 - H91-PHT 5920217 TP02FD-6.P
GENERAL MOTORS
BPT04-PT PT04-PT B-107-HPT B107-PHT 5902386 -
BVX5-PT - - - - -
BB112-PT B111-PT HAT380-CP CMX380CP-HPT 692931 TP12GM-37.P
BB99-PT B99-PT B-99-HPT B99-PHT 692952 TP05GM-28.P
BB97-PT B97-PT B97-HPT B97-PHT 690552 -
BHU46-T2 HU46-T2 - T10HF54-PHT - TP05OP-S.P
- - HAT-2789 - - -
BB114-PT B114-PT HAT-4220 DW47-N-PHT 7011685 TP05DAE-4.P
BB103-PT B103-PT B103-HPT B103-PHT 690556 -
BTOY44D-PT TOY44D-PT HAT-8020 - 5910834 TP30TOYO-15.P
HONDA/ACURA
BHD106-PT HD106-PT H-106-HPT HD106-PT 692246 TP05HOND,21P
BHO02-PT HO03-PT HD-112-HPT HD112-PHT 5907553 TP32HOND.31P
BHO01-PT HO01-PT - - 692082 TP05HOND.31P
BHD108-PT HD111-PT HD-108-HPT HD113-PHT 5907552 TP12HOND.21P
HYUNDAI/KIA
- HYN16T14 - - - -
- HY20-PT - - - -
BHY021-PT HY021-PT - - - -
BKI4TK13 KK7-PT HAT-6310 - - -
- - HAT-4040 - - -
ISUZU
BHD90TK8 - - HD113-ETS-P1 - TP08HOND.21P
JAGUAR
BJAG2-PT - - - - TP06FO.6P
JEEP
BY170-PT Y170-PT HAT-3740 Y166-PHT 5909874 -
BY165-PT Y164-PT HAT-1718 Y165-PHT 692352 TP12CHR.15P
MAZDA
BMAZ24RT5 MAZ24RT5 - MAZ24RT5 692080 TP05MAZ-11D.P
BMZ24TK14 MAZ24RT17 - MZ34-PHT - TP20MAZ-11D.P2
MITSUBISHI
BMIT8-PT MIT8-PT - MIT12-PHT 692058 -
BMIT12-PT MIT12-PT - MIT12-PHT 5907793 TP26MIT-12.P2
BMIT9-PT MIT13-PT HAT-0648 MIT13-PHT 692564 TPX2MIT-18.P
BY165-PT Y164-PT HAT-1718 Y165-PHT 692352 TP12CHR-15.P
NISSAN/INFINITI
BNI04T NI04T HAT-104 DA40-PHT 7003526 -
BNI05T - HAT-0010 - - -
BNSN11T2 NSN11-T2 - DA31-N-PHT - TP05DAT.6P
BNI02T NI02T DA34-HPT DA34-PHT 692061 TP19DAT.15P2
SAAB
BPT04-PT PT04-PT B-107-HPT B107-PHT 5902386 TP05VGM-37.P
SATURN
- - HAT-2428 - - -
BB112-PT B111-PT HAT380-CP CMX380CP-HPT 692931 TP12GM-37.P
BB97-PT B97-PT B97-HPT B97-PHT 690552 -
BB114-PT B114-PT HAT-4220 DW47-N-PHT 7011685 TP05DAE-4.P
SCION
BTOY44D-PT TOY44D-PT HAT-8020 - 5910834 TP30TOYO-15.P
SPRINTER
BYS15TK1 YM15T5-SI - YS15TK1 - TP05ME-HM.P1
SUBARU
- SUB4-PT HAT-9711 - - TP28SUB-3.P
- - HAT-9770 - - -
SUZUKI
BNI04T NI04T HAT-104 DA40-PHT 7003526 -
BB112-PT B111-PT HAT380-CP CMX380CP-HPT 692931 TP12GM-37.P
TOYOTA/LEXUS
BTOY43AT4 TOY43AT4 TR47-HPT TR47-PHT 692062 TP07VTOYO-15.P
BTOY44D-PT TOY44D-PT HAT-8020 - 5910834 TP30TOYO-15.P
BTOY40BT4 TOY40BT4 TR49-HPT TR49-PHT - TP07TOYO.18P
BTOY48BT4 - HAT-2010 - - -
BTOY50-PT - - - - -
VOLKSWAGEN/AUDI/PORSCHE
BHU66AT6 HU66AT6 HU-67-HPT HU67-PHT - TP08HU-HAA.P
BY170-PT Y170-PT HAT-3740 Y166-PHT 5909874 -
BHU66T5 HU66T5 - - - TP05HU-HAA.P1
